Introduction - 1 - 2 - 3 - 4
  1. #11 Remove the template and cut out the door line, then tape this back in exact position. Using the template as a guide, VERY CAREFULLY, and with quite light pressure on the Scriber, start scribing a new door line. Until you have a good trench going, keep the template in place. Once you have a good depth, you can remove the template and finish cutting the door line to the depth you prefer. Flop the template and use it for cutting the door line on the other door, measuring carefully to make sure the doors are in the same position on each side of the model.
  1. #12 On this model I extended the bottom of the door line first as it had its own guide line in the rocker panel molding.
  1. #13 The technique for making the template for the back door of this model is different than for the front door. For this door it is easiest if you cut the door shape out first. Keep checking to make sure you have it accurate, then tape this template to the body, and again mark the forward edge in case you have to remove the template - you want to be able to get it in exact position again if necessary.
  1. #14 I scribe the easy cuts first. Then cutout in the roof and the straight cut; then tape the back of the template to the body to better hold it in place. The curved cuts (and corners) are a bit more tricky, but not really all that much more difficult. Just use a very light touch for the first passes until you have a good trench going. Start at one end of the door line and work to connecting with the other. This motion need not be in one stroke - whatever is comfortable for you, one long stroke, or several connected short ones. Just keep working the line until you have the depth of the cut equal to the other lines.
  1. #15 Once the door lines are pretty much at the correct depth, draw the scriber, using light pressure, back and forth along the line, in a "sanding" motion. This will smooth out the scribe a great deal and give the model a more finished look.

Introduction - 1 - 2 - 3 - 4
